Appendix
AX3000 Models 90 - User's Manual 269
☺: In contrast to some implementations Axel uses a ‘keyword’ rather than a
specific number. The actual number (231 to 240) is irrelevant so any non-
conflicting number in this range can be used.
For more information on the Axel options see chapter A.5.3.
A.5.2 - Adding an Axel option with the Microsoft DHCP Server
To add an Axel DHCP option with Microsoft’s DHCP server see below:
1 - Launch the DHCP utility.
Right click on the IP address of the DHCP server and select ‘Set Predefined
Options’ and select ‘Add'
2 - The following dialog box is displayed:
Complete the fields as follows:
- Name = (User definable) for example ‘Axel Autoconf’
- Data Type = (mandatory) string
- Code = (User definable) select unused number between 231 and 240
- Description = (User definable) for example "Axel vender option for auto-
configuration".
Click ‘OK’ to exit this box and 'OK' again to exit the former box.
3 - In the left panel select 'Server Options’ then right click ‘Configure Options’
Within the available options ‘tick’ the new Axel entry and enter IP and TCP port
