Axel AX3000 User Manual

Installing under OS/400
170 AX3000 Models 90 - User's Manual
6.2.2 - Using the Keyboard
Two types of keyboard can be used with the AX3000: a PC/AT (102/105-key) or
a 5250 (122-key) keyboard. The following tables list the 5250 functions and the
Axel functions (entering the set-up, etc) accessed from these keyboard.
5250 Functions:
5250 Functions
5250 Keyboard
PC/AT Keyboard
Attention
<Attn>
<Esc> or <Alt Gr><Pause>
Back tabulation
<|> or <Shift><|>
<Shift><Tab>
Clear end of field
<ErInp>
<End>
Clear all fields
<Alt><Clear>
<Pause>
Cursor shape (Ch. 6.1.3)
<Cursor>
<Alt Gr><F11>
Duplication
<Dup>
<Shift><Insert>
Enter
<Enter>
<Enter>
Euro symbol
<Alt><E>
<Alt Gr><E>
Execute macro
<Exec>
<Alt Gr><F5>
F1...F12
<F1>...<F12>
<F1>...<F12>
F13...F24
<F13>...<F24>
<Shift><F1>...<Shift><F12>
Fast left
<Shift><>
<Shift><>
Fast right
<Shift><>
<Shift><>
Field -
<Field ->
<-> (numpad)
Field +
<Field +>
<+> (numpad)
Field Exit
<Field Exit>
<Entr> (numpad)
Help
<Help>
<Alt Gr><F1>
Hexa
<Alt><Help>
<Alt Gr><F7>
Home of field
<Alt><Rule>
<Home>
New Line
<>
<Ctrl Right>
Print (local mode in PC850)
<Rest><Alt><Print>
<Ctrl><Alt><Prt Scr>
Print (Print HOST mode)
<Print>
<Prt Scr>
Record Macro
<Record>
<Alt Gr><F4>
Reset
<Rest>
<Ctrl Left>
Roll Down
<Shift><↓>
<Page Up> or <Shift><↓>
Roll Up
<Shift><↑>
<Page Down> or <Shift><↑>
Rule (see Chapter 6.1.3)
<Rule>
<Alt Gr><F12>
System Request
<Shift><Attn>
<Shift><Esc> or <Alt Gr><Prt Scr>
Tabulation
<|>
<Tab>
