Installing under Windows
AX3000 Models 90 - User's Manual 155
5.5.1 - Setting-Up the AX3000
To set the LPD service on the thin client port, select the [Configuration]-[Ports
aux.]-[xxx]-[yyy] dialog and enter the following parameters:
- Associated Service: select lpd.
- Net Service Parameters:
- Printer Port Name: this is the port identifier. Sometimes the same
name is used for the printer at the operating system level.
- NL=CR+NL Filter: set to "no",
- Enhanced parameters: see Appendix A.7.3.
- Pre-print String: normally not used.
- Post-print String: normally not used.
Note 1: If "Choose Portrait/Landscape" is enabled (see Appendix A.7.2), the
parameter "Pre-print String" is replaced by the two parameters "Portrait Pre-
print String" and "Landscape Pre-print String".
Note 2: if the auxiliary port used for printing is a serial port, set the 'Printer'
operating mode.
5.5.2 - Setting-Up the Windows Server
To add a printer, select the 'Add printer' icon. Within the displayed dialog box,
select 'Local printer' (Disable the Plug-And-Play detection). Click on 'Next'.
Within the next dialog box, select 'Create a new port' and select 'LPR Port'.
Click on 'Next'.
Note: if 'LPR Port' is not available, you need to install 'Print Services for Unix'
from the Windows CD-Rom.
