Interactive Set-Up
AX3000 Models 90 - User's Manual 39
Note: If the 'Default Router' is selected in the "DHCP Option List", this field
cannot be accessed.
However additional routers can also be declared, to reach specific destination
servers or networks. Select 'Other Routers'. The following dialog box is
displayed:
Any such router must be identified with 3 parameters:
- The router’s IP address,
- The target IP address (destination),
- The target type: server or network (in this last case, a netmask allows
sub-netting)
3.1.3 - Wireless Interface
To set the Wireless interface properties select the [Configuration]-[Network]-
[Wireless Interface] menu. The two sub-menus are:
- [Wireless Parameters]: see next page.
- [IP Parameters]: same dialog box as Ethernet interface (minus the 'Link'
parameter)
