Interactive Set-Up
AX3000 Models 90 - User's Manual 73
3.4.3 - Connecting a USB Barcode Reader
The USB barcode reader is automatically detected by the Axel thin client. A
barcode reader is treated as a keyboard. See previous chapter.
3.4.4 - Connecting a Mouse
A USB mouse is automatically detected by the Axel thin client. No specific
settings are required.
Note: multiple mice (USB and/or PS2) can be used simultaneously.
3.4.5 - Connecting a HUB
A USB HUB is automatically detected by the Axel thin client. No specific
settings are required.
3.4.6 - Connecting a Printer
a) Logical Port Attachment
When a USB printer is connected for the first time to the Axel thin client a logical
port is associated. Four logical ports are available: Usb1, Usb2, Usb3 and Usb4.
The associated logical ports are listed in the menu [Configuration]-[Ports]-
[USB Logical Ports]. To get information of a USB printer, select its logical port.
For example:
