Axel AX3000 User Manual

Installing under OS/390
AX3000 Models 90 - User's Manual 193
Keyboard Symbols
Symbol
Meaning
X ()
Keyboard is disabled
X
Only <Enter> is disabled
X >
Error: too much data entered. Press <Reset>
X NUM
Error: numeric value must be entered. Press <Reset>
X ← →
Error: invalid cursor position. Press <Reset>
Mode Symbols
Symbol
Meaning

<Shift> is currently pressed or the keyboard is in Caps Lock
mode
^
The insert mode is enabled (<Inser> key)
R
The "Record" mode is set (see Chapter 6.2.3)
P
The "Process" mode is set (see Chapter 6.2.3)
LL/CC
LL and CC indicate the row and column where the cursor is
located
7.2.2 - Using a PC/AT Keyboard (102/105 keys)
The IBM 3270 emulation enables a PC/AT keyboard to be used for operation as
a 3270 terminal.
The first twelve 3270 function keys are accessed through <F1> to <F12>. The
F13 to F24 function keys are accessed through <Shift><F1> to <Shift><F12>.
