Installing under OS/400
AX3000 Models 90 - User's Manual 169
following information:
System Available Upper Shift
Message(s) Waiting Caps Lock Function key Assignment
Input Inhibit Insert
  X  A ^ ð R 63    LL/CC
Available Keystrokes Cursor
Mode: R (Record) Locator
P (Process)
Diacritic Mode
The status symbols are described in the following table.
Symbol
Name
Meaning

System
Available
The host system is operating and available

Message(s)
Waiting
This symbol, and a beep, indicate the host system
has one or more messages for the thin client.
X
Input Inhibit
This symbol is displayed when:
- the host system is processing the last input
- the host system is very busy
- the host system detects an error condition

Upper Shift
<Shift> is currently pressed
A
Caps Lock
The keyboard is in Caps Lock mode
^
Insert
The insert mode is enabled (<Inser> key)
ð
Diacritic Mode
This symbol is displayed when the diacritic mode is
enabled. This mode is automatically set when a
composed character is currently entered (^ + e = ê)
R
Record
The "Record" mode is set (see Chapter 6.2.3)
P
Process
The "Process" mode is set (see Chapter 6.2.3)
LL/CC
Cursor
Locator
LL and CC indicate the row and column where the
cursor is located
