baxter Starling - Figure 5-45 Bolus Test - Challenge in Progress

©2020 Baxter International Inc. 5- 49
Performing a Dynamic Assessment Test
Note Prepare 250 ml to be infused in 5 minutes or less
1,2
OR
Prepare 500 ml to be infused in 10 minutes or less
1
,
2
4. As instructed, start intravenous administration of the Bolus (in accordance with
clinical standards/protocols), then tap Next.
The Challenge commences.
While the Challenge is in progress, the Dynamic display shows a second graph being
drawn on the right side of the screen; on the left, a Challenge timer (counts up in
min/secs) is seen. See the example in Figure 5-45.
1. Aya HD et al . Pharmacodynamic analysis of a fluid challenge. Crit Care Med 2016; 44:880–891
2. Cecconi M et al . What is a fluid challenge? Curr Opin Crit Care 20 11:17:290-295
Figure 5-45 Bolus Test - Challenge in Progress
Challenge
Timer
Challenge
Graph
Test
In Progress
