6-10 Starling Monitor - User Guide
Fuse Replacement Procedure
Fuse Replacement Procedure
The Starling Monitor is equipped with two mains AC fuses to protect against accidental short-
circuits. The fuses are rated at 2A SB.
 To Replace a Fuse
1. Perform the System Shutdown Procedure, then disconnect the AC power cable from
the mains power wall outlet.
2. Working from the Starling Monitor rear panel, press
down
on the plastic clip beneath
the AC power input socket to release the fuse housing, then pull the drawer out to
completely remove it from the rear panel - see Figure 6-6.
WARNING
Before replacing a fuse, always ensure power to the Monitor is OFF and the AC power cable
is disconnected from the mains power wall outlet.
Use fuses of the same type and rating ONLY.
Figure 6-6 Fuse Replacement - Removing the Fuse Housing Drawer from the Rear Panel
