©2020 Baxter International Inc. 2- 11
System Configuration
Figure 2-6 Starling Monitor - Front View (Operator Panel)
4
2
3
5
1
Legend, Figure 2-6
1
Touch Screen - LED Display
2
Power On Button
3
Back Button
4
Main Menu Button
5
Display Control Knob
