SpO
2
Module (Optional)
Place the sensor on a thin part of the patient’s body (e.g., fingertip or earlobe, or in the case
of an infant, across a foot). To start SpO
2
monitoring while running a Session, select Start
SpO2 from the main menu (if SpO2 automatic mode is not the default mode.)
When this is done, SpO
2
monitoring commences automatically.
NELL-1 SpO
2
Module Specifications
Table C-5 NELL-1 SpO
2
Module Specifications
Item Specifications/Details
Patient Range Neonate through Adult
Saturation 1% to 100% SpO
2
OPERATING CONDITIONS
Operating Temperature 0°C to +60°C (32°F to 140°F)
Relative Humidity 15% to 95% non-condensing
Altitude 1,000 feet below sea level to 10,000 feet above sea level
Operating Mechanical Shock Per IEC 600068-2-27, 100G, 6 ms half sine
Operating Sinusoidal Vibration Per IEC 600068-2-6, 10 Hz to 500 Hz, 1 G peak, 10 sweeps/axis
Operating Random Vibration Per IEC 600068-2-34, 20 Hz to 500 Hz, 0.02 g2/Hz
SHIPPING & STORAGE CONDITIONS
Storage Temperature -40°C to +70°C (-40°F to 158°F)
Relative Humidity 15% to 95% non-condensing
Storage Altitude 1,000 feet below sea level to 20,000 feet above sea level
Vibration Per NSTA Project 1A
Drop Per NSTA Project 1A
