System Configuration
Buttons
Power On Button
The Power On Button on the front of the Operator Panel (top right) is used to
commence the system start-up procedure.
Illumination of the On button provides an indication of system power status, as
outlined in Table 2-1.
Note For an explanation of battery status indicators seen on the display, refer to Table 2-2 on page 2-16.
Main Menu Button
Back Button
Used to close a sub-menu.
Table 2-1 Power On Button - Power Status Indicators
LED Illumination Monitor Power
Monitor Connected
to Mains Power
Comment
Red - steady OFF Yes
Red - blinking OFF Yes Battery charging in progress
Orange - steady ON No
Green - steady ON Yes
 If no Monitoring Session in progress:
Press once to open the Quick Access menu; press x to close the menu.
 If Monitoring Session currently active:
Press once to open the Main menu; press again to close.
