2-26 Starling Monitor - User Guide
System Configuration
Starling IV Pole Mount Connector
The Starling IV Pole Mount Connector is an optional accessory approved by Cheetah Medical
for use with the Starling Monitor.
This custom-shaped connector is specially designed to provide a convenient mounting option,
enabling the Starling Monitor to be clamped securely onto an IV pole.
Note
For mounting instructions, see Attaching the Starling IV Pole Mount Connector
on page 4-5
Figure 2-14 Starling IV Pole Mount Connector
Connector (includes 4 mounting screws)
Connector attached to Monitor rear panel
