Theory of Operation
 If the Stroke Volume increase is >10%, the patient is determined to be
fluid responsive
.
1
This is also represented on the Starling Monitor by the estimated location of the indicator
on the Frank-Starling curve. This will be on the steep ascending portion - example shown in
Figure 2-4.
 If the Stroke Volume increase is <10% the patient is considered not to be fluid responsive.
1
The indicator will be approximately close to or on the top part of the Curve:
1. Bentzer P et al. JAMA 2016; 316:1298.
Figure 2-4 Stroke Volume Increase >10% - Indicates Patient is Fluid Responsive
Figure 2-5 Stroke Volume Increase <10% - Indicates Patient is Not Fluid Responsive
Indicator on
Frank-Starling Curve
Indicator on
