5-48 Starling Monitor - User Guide
Performing a Dynamic Assessment Test
As soon as the countdown reaches zero, Baseline measurement is complete.
The system sounds a single beep; the next instruction is displayed (Figure 5-44).
Note In the event that the Baseline results are considered by the system to be unstable, a warning
message is displayed. The user has the option of nevertheless continuing to the Challenge stage, or
restarting the Test again from the Baseline stage.
Figure 5-43 Bolus Test - Baseline Measurement in Progress
Baseline
Countdown
Baseline
Graph
Test
In Progress
Figure 5-44 Bolus Test - Measure SVI Change
