Capintec CAPTUS 3000 - Export Raw Spectrum; Save MCA Settings; Recall MCA Settings

CAPINTEC, INC. CAPTUS
®
3000
Figure 13-15
Export Raw Spectrum
The MCA the raw spectrum count data can be exported to Excel format. This includes counts
in all channels (it does not include the active ROIs). To export the raw spectrum data, choose
Export Raw Spectrum from the
button on the menu bar. A dialog box
similar to the Save Spectrum dialog box will appear (as shown in Figure 13-13), but the file
extension will be .xls.
Note: It is recommended that the Save as type: is not changed from MCA Spectra (*.xls)
Save MCA Settings
In order to store the MCA settings for later retrieval and use, choose Save Settings from the
button on the menu bar. A dialog box similar to the Save Spectrum
dialog box will appear (as shown in Figure 13-13), but the file extension will be .set.
Input the desired file name for the settings. The default folder will be C:\Captus3000\Data. To
save the data to another folder, browse to the desired location, then input the file name. To
save the settings, click the
button.
Note: It is recommended that the Save as type: is not changed from MCA Settings Files
(*.set)
The MCA settings, such as voltage, gain, zero, threshold, and defined ROIs will be stored in
the file.
Recall MCA Settings
To retrieve stored MCA settings, choose Load Previous Settings from the
button on the menu bar. A dialog box similar to the Load Spectrum
dialog box will appear (as shown in Figure 13-14), but the file extension will be .set.
13-12 MCA November 13
