CAPINTEC, INC. CAPTUS
®
3000
Figure 5-26
• To print current results for record keeping, click the button or press
Alt+P on MDA Test screen after the test is completed.
• To view or print results for all the Quality Assurance tests performed to date,
click the button or press Alt+V (Refer to the
VIEWING AND
PRINTING HISTORY section on page 5-24).
VIEWING SYSTEM PARAMETERS
This function provides access to all the parameters used for the measurements and
calculations of results in all procedures (Thyroid Uptake, Lab Tests, Wipe Test, QA Tests
etc.) provided by the CAPTUS
®
3000 system.
1. Click the button or press Alt+P on Figure 5-1 Quality Assurance
Main Screen. The screen appears similar to that shown in Figure 5-27. You may scroll
down to see all of the parameters. The system details appear at the top followed by the
Quality Assurance parameters. Below that, setup values are listed for each type of
procedure.
5-22 QUALITY ASSURANCE July 14
