CAPINTEC, INC. CAPTUS
®
3000
Thyroid Uptake
Wipe Test
Schilling Test
Blood Volume
RBC Survival
MCA
TUS Probe Detector
NaI(TI) flat face crystal / PM Tube: ... 5.1 x 5.1 cm ... (2” x 2”)
Monoline construction
Resolution (Full Width-Half Max) – ≤9.5% or better for Cs137
Lead Shielded Collimator
Complies with ANSI Standard N44.3-1973
10 ft. (maximum) coaxial signal/high voltage cable
Well Detector – Optional
With attached 10 ft. (maximum) coaxial signal/high voltage cable. (Allows for the
placement of the Well away from the Stand.)
NaI(TI) well type crystal / PM Tube: .. 5.1 x 5.1 cm ... (2” x 2”)
Well diameter: ....................... 1.6 cm ............ (0.625”)
Well depth: ............................ 4 cm ............... (1.5”)
Monoline construction
Resolution (Full Width-Half Max) – ≤10.0% or better for Cs137
Lead shielding – lined with brass (0.16 cm (1/16”) thick) to minimize backscatter
Thickness:............................. 2.5 cm ............ (1”)
Height: .................................. 32.5 cm .......... (12.8”)
Diameter: .............................. 11.4 cm .......... (4.5”)
Weight: ................................. 27.9 kg ........... (61.4 lb.)
Environment Requirements
Operational
The instrument should be located where the level of the background radiation is as
low and as constant as possible.
The instrument should be located where the temperature is stable within a range of
+50°F to +85°F (+10°C to +30°C) and the maximum relative humidity is 90% non-
condensing for maximum reliability and accuracy.
The instrument should be located where the barometric pressure is within a range of
27–31 inches of mercury (91–105 kilopascals).
2-8 FUNCTIONAL & TECHNICAL DESCRIPTION July 14
