ComAp InteliDrive DCU Marine User Manual

InteliDrive DCU Marine - 3.0.0 Global Guide
114
Setpoint group Basic settings Related FW 3.0.0
Range [units] [PRIMARY, SECONDARY, BIN.INPUT]
Default value PRIMARY
Step [-]
Comm object 10231 Related applications AUX, EME, CMB
Config level Standard
Setpoint visibility Always
Description
Activates/deactivates the logical binary output Secondary Sw. This output can be configured to J1939
output to switch ECU Nominal – RPM.see Logical BI in table below.
BIN.INPUT: PRIMARY / SECONDARY Nominal RPM is selected via Binary input BI Secondr RPM – see
Logical BI in table below.
Setpoint name Setpoint setting Logical BO Logical BI
Governor Mode ISOCHR / DROOP / BIN.INPUT Droop Sw BI Droop
Speed Select PRIMARY / SECONDARY / BIN.INPUT Second RPM Sw BI Secondr RPM
Idle/Nominal IDLE / NOMINAL / BIN.INPUT Nominal Sw BI Idle
Note: Basic setting: Nominal RPM must correspond to ECU Nominal RPM for 100% Throttle position in
PRP and 50% in AUX.
Speed Select
6 back to List of setpoints
Setpoint group Basic settings Related FW 3.0.0
Range [units] [AUTO, INTERNAL, ECU]
Default value AUTO
Step [-]
Comm object 8630 Related applications All
Config level Standard
Setpoint visibility Always
Description
AUTO – controller displays valid running hours value received from any ECU module. In case of erratic
reading use option ECU and parameter RHS Index to define module, which is source of running hours.
Running hours value calculated by controller is used, if no valid value is received.
INTERNAL – ID-DCU MARINE running hours statistical value is used
ECU – controller reads running hours from selected ECU module. Parameter RHS Index is used to select
index of module, from which controller reads running hours.
In case no ECUsupport is configured, internal running hours value is used despite RunHoursSource setting.
RunHourSource
6 back to List of setpoints
