4.2.7 Wiring example - Complete system without RPU
4.3 Getting started
4.3.1 How to install
Note: All components shall be used within marked electrical ratings – see chapter Technical data.
Binary output protections
Do not connect binary outputs directly to DC relays without protection diodes. Use protection diodes even if the
relays are not connected directly to controller outputs. Use a fast recovery 3A / 50V diodes.
Image 4.4 Example of controller protection
