InteliDrive DCU Marine - 3.0.0 Global Guide
23
Note: The WebSupervisor ComAp tool is supported from ID-DCU Marine version 2.2, specifically fromID-
DCU-MARINE-W-2.2.mhx firmware.
2.3 List of supported modules
Product Description Order code
Inteli AIN8 8 Analog inputs (R, I, V) and 1 pulse/frequency input I-AIN8
Inteli AIN8TC 8 Thermocouple Analog inputs I-AIN8TC
Inteli IO8/8
8 Binary inputs, 8 Binary outputs and 2 Analog outputs packed in
a small unit (HW switchable to IO16/0). HW switchableto IO16/0
- 16 Binary inputs
I-IO8/8
IS-BIN 16/8
16 configurable galvanically separated inputs, 8 configurable
outputs
IS-BIN16/8
Inteli AIO9/1 9 Analog inputs (4x DC, 4x thermocouples, 1x R) I-AIO9/1
IS-AIN8 8 Analog inputs packed in a rugged metal unit IS-AIN8
IS-AIN8TC
8 analog inputs for thermocouple measurement, supports J, K, L
types
IS-AIN8TC
IGS-PTM
8 Binary inputs, 8 Binary outputs, 4 Analog inputs and 1 Analog
output
IGS-PTM
IB-NT Internet bridge IB-NT
I-CB Communication bridge I-CB
I-AOUT8 8 Analog outputs I-AOUT8
You can get more information on wiring of standard extension modules in the chapter Extension modules
(page 69).
