InteliDrive DCU Marine - 3.0.0 Global Guide
18
Record in Alarm list
State machine indication
Oil Pressure (MainScrAna1) indication
Coolant Temperature (MainScrAna2) indication
RPM indication
2.2 Controller configuration and monitoring
InteliDrive sw pack contains separate PC software tools: DriveConfig (DC) and InteliMonitor (IMON).
DriveConfig and InteliMonitor is based on Windows 2000/XP/Vista/Win7/Win8 or higher platform.
2.2.1 AirGate connection to the PC
This connection type is used for connection to controller (s), that are connected to the Internet, however they do
not have public and static IP address. The controllers connect by InternetBridge-NT module to the AirGate
server and cyclically ask whether there is a connection request from a client or not. On the other side the clients
(only ComAp PC applications - DriveConfig, DriveMonitor InteliMonitor and WebSupervisor) connect to the
AirGate server instead of connecting directly to the controller. The server then creates a "tunnel" between the
client and the controller.
Note: InternetBridge-NT (IB-NT) connection into Internet network can be done via Ethernet or Cellular
connection. The Ethernet connection can be realized by direct access using fixed and public IP address as well
as by private network access using dynamic non-public IP address (behind Firewall, NAT, DHCP server etc. –
situation illustrated in the picture above).
