InteliDrive DCU Marine - 3.0.0 Global Guide
144
RPMdep protect (PRP only)
RPM dependent Oil pressure and Coolant pressure protections are available in PRP (propulsion) application
only. Both protections are by default set to Protection block type = RunOnlyBlkDel1 (Engine running - block
delay 1).
There are two setpoints for linear Warning limit, two for Shutdown limit and one for delay. Setpoints adjusting
step and range depends on corresponding sensor characteristics.
Note: The particular RPM dependent protection is fully disabled if both xxxIdlexxx and xxxNomxxx parameters
are set to value 0,0. I.e. the protection is not activated even if measured value is negative (e.g. when there is a
wrong sensor calibration).
Setpoint group RPMdep Protect Related FW 3.0.0
Range [units] 0,0 .. 10,0 [Bar]
Default value 0,0
Step 0,1
Comm object 10140 Related applications PRP
Config level Standard
Setpoint visibility Always
Description
Linear Warning characteristic is defined by two points for Idle RPM and Nominal RPM.OPIdleRPMWrn
defines oil pressure warning level at idle speed.
OPIdleRPMWrn
6 back to List of setpoints
