InteliDrive DCU Marine - 3.0.0 Global Guide
250
Related FW 3.0.0 Related applications All
Comm object 182
Description
There are two Statistics registers Memo1 and Memo2. Those statistic values are based on Logical Analog
Input Memory1 or Memory2 value in the time of Logical Binary input Memo1 Trigger or Memo2 Trigger rising
edge. Both statistics values is possible to modify in InteliMonitor – Set Statistics command.
Memory2
6 back to List of LAI
Related FW 3.0.0 Related applications All
Comm object 56
Description
If there is an additional terminal board between a thermocouple sensor and the IS-AIN8 (TC) module and
there is a significant temperature difference between this terminal board and the module, it is necessary to
measure the temperature at this terminal board and use this temperature for the thermocouple compensation
instead of the internal temperature of the module.
Cold Temp 1 Logical Analog input is intended for measurement of this thermocouple compensation
temperature for the IS-AIN8 (TC) module with index #1, Cold Temp 2 corresponds to IS-AIN8 (TC) module
with index #2 etc.
Note: Thermocouples without internal compensation "Thermo(nc)..." must be used for this case.
Cold Temp 1
6 back to List of LAI
