InteliDrive DCU Marine - 3.0.0 Global Guide
105
8.1 Controller objects
8.1.1 List of controller objects types
8.1.2 Setpoints 105
8.1.3 Binary Inputs 174
8.1.4 Binary outputs 196
8.1.5 Analog Inputs 242
8.1.6 Values 262
6 back to Appendix
8.1.2 Setpoints
What setpoints are:
Setpoints are analog, binary or special data objects which are used for adjusting the controller to the specific
environment. Setpoints are organized into groups according to their meaning. Setpoints can be adjusted from
the controller front panel, PC, MODBUS, etc.
Each setpoint can be protected by a password against unauthorized changes. Password protection can be
assigned to the setpoints during the configuration procedure.
IMPORTANT: Do not perform repeated writing of setpoints (e.g. do NOT have a MODBUS
’watchdog’ system where PLC periodically writes down a figure into register and then reads the
figure). The setpoints are stored in EEPROM memory, which can be overwritten up to 100 000 times
without risk of damage or data loss, however it may become damaged, when allowed number of
writing cycles is exceeded!
The issue with EEPROM memory limit is resolved from ID-DCU MARINE firmware version 2.2,
setpoint registers were moved into another memory part of the controller.
List of setpoint groups
Password 109
Engine commands and Statistics protection 110
Basic settings 111
Comms settings 117
Engine params 123
Engine protect 134
RPMdep protect (PRP only) 144
Load sharing 149
Analog inputs 158
Act. Calls/SMS 161
Date and Time 168
ID-SCM unit 170
DetCon20 171
Protections 174
