Page #189 background imageLoading...
Page #189 background image
InteliDrive DCU Marine - 3.0.0 Global Guide
189
Related FW 3.0.0 Related applications All
Comm object 167
Description
This input changes state of logical binary output Droop Sw that can be configured as J1939 output to
change ECU mode. Input is active only when Basic setting: Governor Mode = BIN.INPUT (DROOP when
closed).
BI Droop
6 back to List of LBI
Related FW 3.0.0 Related applications All
Comm object 168
Description
This input changes state of logical binary output Second RPM Sw that can be configured as J1939 output to
change ECU mode. Input is active only when Basic setting: Speed Select = BIN.INPUT.
BI Second RPM
6 back to List of LBI
Related FW 3.0.0 Related applications All
Comm object 169
Description
This input changes state of logical binary output Idle/Nominal that can be configured as J1939 output to
change ECU mode. Input is active only when Basic setting: Idle/Nominal = BIN.INPUT.
BI Idle
6 back to List of LBI
Related FW 3.0.0 Related applications All
Comm object 172
Description
Rem Start/Stop is level signal that activates engine start when closed and stop after is opened. It is inactive
in LOC (Local) mode.
It is not possible to stop engine by panel Stop button and by Binary input Remote Stop when Rem Start/Stop
is active. Rem Start/Stop input can be configured to Binary output Timer active to enable engine automatic
start/stop function see Basic settings / Timer setpoints.
Note: Engine Start fail” is Warning (level 1) protection and does not block another start when Rem
Start/Stop is still closed. To prevent unlimited number of starts configure on LBO Start fail Sd
protection.
Note: Engine stays running when Rem Start/Stop is opened in controller LOC (Local) mode.
Rem Start/Stop
6 back to List of LBI
