Page #9 background imageLoading...
Page #9 background image
InteliDrive DCU Marine - 3.0.0 Global Guide
9
temperature (alternatively Aftertreatment values)
Indication: LOC (Local), Alarm (in AL or ECU list), R Remote data
connection active, L Access Lock
2 Analog 1 to Analog 4 , 4x single barograph
3 Analog 5 to Analog 8 , 4x single barograph (if they are configured)
4
Battery ID-DCU MARINE, bargraph, Engine Cylinders statistic
temperatures, Engine states timer
5 ID-DCU MARINE BI 1 to 7
6 ID-DCU MARINE BI 8 to 14
7 ID-DCU MARINE BO 1 to 7
8 ID-DCU MARINE BO 8 to 14
9 Statistics: Run hours, Number of starts, Service time
10 GPS speed (value is shared from other devices)
Following screens appears depend on configuration
Opt
Analog 1 to Analog 8, Name- value dimension, active alarm is
negative (1x IS-AIN8(TC) or Inteli AIN8(TC))
Opt IS-BIN BI indication 1 to 8
Opt IS-BIN BI indication 9 to 16
Opt IS-BIN BO indication 1 to 8
Opt ECU values I.
Opt ECU values II.
Setpoints screens correspond with Setpoint table above.
Alarm indication
Possible Alarm list and History record prefixes
Prefix Meaning
Wrn Warning
Sd Shutdown
Cd Cooldown
Bw Broken wire
Fls Sensor fail
Three state Alarm list indication
* Wrn Water temp Active not accepted alarm
Wrn Water temp Active accepted alarm
* Wrn Water temp Inactive not accepted alarm
Inactive accepted alarm
