4 Installation and wiring
4.1 Terminal and dimensions
4.1.1 ID-DCU MARINE
The front panel of the InteliDrive controller is intended for installation in an overall enclosure – rubber seal for IP
65 - Technical data (page 100)
Left RED Active alarm indication
Blinks when new alarm is activated.
Steady lights after "Fault reset" confirmation - when
alarm is still active.
Disappears after "Fault reset" confirmation.- when alarm
is inactive.
Right GREEN Engine running indication Light when engine is running.
Front panel LED
Note: Please check the last software version.
