Analog output refreshment: 100 ms
Analog output options
PWM 1600 Hz (fix), 5V level, max 10 mA
0 to 10VDC ± 1%, 10 kΩ output resistance
0 to 10VDC ± 1%, max 5 mA (voltage output)
Configuration in DriveConfig
Module = SCM
I/O – Analog outputs – SCM - AOUT1 (only)
Source
Low convert limit
Hi convert limit
Description
ID-SCM1 can only be configured as ID-SCM.
ID-SCM1 has only 1 analog output unlike ID-SCM which has 3 AOUTs (plus 4 values and 4 setpoints).
Control value Speed Governor is send on ID-SCM1 AOUT - equivalent output on ID-SCM is 3rd AOUT
(with PWM)
Invalid values are shown in SCM values
SCM setpoints are not used (sepoints not affects the function)
Note: Maximal torque to tight main screw is 0.25 Nm.
4.1.11 InteliVision 5 CAN, InteliVision 5 CAN Backlit
5” color display. InteliVision 5 CAN is offered in two hardware modifications:
InteliVision 5 CAN
InteliVision 5 CAN Backlit
The only HW difference between two versions is presence of standard or backlight keyboard version, i.e. if
there is present a feature of back-lighted buttons or not. Both versions are IP65 protected from all sides,
equipped with binary output switch for HORN signaling, CAN interface is galvanically separated.
The InteliVision 5 CAN version is intended to use with InteliDrive controllers only (ID-DCU, ID-DCU MARINE,
ID-Mobile, ID-Mobile Logger), Backlit version supports also InteliGen-NT and InteliSys NT controllers.
Depending on customer preferences there can be used optional accessories:
InteliVision 5 Harness-2
2m prefabricated cable with unassigned wires at the end
InteliVision 5 IP 65 Connector
connector set containing connector body and 10 corresponding terminal female pins
ECU Simulator
set containing supported USB/CAN converter and various cabling, for new firmware / font / logo
download into the InteliVision 5 CAN
