InteliDrive DCU Marine - 3.0.0 Global Guide
33
Symbol Meaning
SD1 .. SD5 State of all binary inputs SD1-SD5
BW1 .. BW5 State of all BW protections
PRIFAIL Primary A battery fail = switched to B battery
ESTOP Binary input Emergency stop state
BWSS Stop solenoid output BW indication
BWFS Fuel solenoid output BW indication
Binary information from ID-RPU to ID-DCU MARINE
Symbol Meaning
COMMWRN Binary output Common warning
COMMSD Binary output Common shut down
FUELSOL Binary output Fuel solenoid
STOPSOL Binary output Stop solenoid
MODE Controller application AUX - EME (or Sd override active)
Binary information from ID-DCU MARINE to ID-RPU
3.2.1 ID-RPU functions
ID-RPU (InteliDrive Redundant Protection Unit) is designed for marine applications. This no microprocessor
unit provides redundant engine protection, RPM measuring and back-up power supply switching for the control
system.
ID-RPU monitors InteliDrive central unit and in the case of fail switches itself to the backup mode or Emergency
backup mode and protects the engine using its own binary EMERGENCY STOP and SHUT DOWN inputs and
FUEL and STOP SOLENOID outputs.
The ID-RPU unit has three operational modes:
Normal
ID-DCU MARINE is working and periodically sends the watchdog impulses to the ID-RPU. All ID-RPU
inputs and outputs are processed via ID-DCU MARINE.
Backup
ID-RPU unit doesn’t receive watchdog impulses from the ID-DCU MARINE. The Shut down (Sd1 to
Sd5), Emergency stop inputs (fix 0,5 sec delay) and Overspeed protection are processed via RPU only.
ID-RPU stays in the mode that was before ID-DCU MARINE fail.
Emergency backup
ID-DCU MARINE was in EME mode (or Sd override function was active) before fail. The only
Emergency stop and Overspeed protection is active in this mode. Shut down Sd1 to Sd5 inputs are
inactive. ID-RPU starts to Emergency backup mode after power on without active ID-DCU MARINE.
