InteliDrive DCU Marine - 3.0.0 Global Guide
178
Note: When Remote Lock is active, it is still possible to initiate programming of a remotely connected
InteliMonitor.
6 back to List of LBI
Related FW 3.0.0 Related applications All
Comm object 5
Description
Active Binary input switches ID-DCU MARINE display backlight between two adjustable intensity levels.
Alternative intensity of the backlight can be set independently by ID-DCU MARINE panel buttons:
1. Hold Enter and press Page to switch to ID Info screen (from any measure screen)
2. Hold Enter and pres / ¯ arrow key to increase/decrease display brightness
The adjusted intensity is stored in non-volatile memory.
Note: Both backlight levels are default (from production) set to maximum.
Low Brightness
6 back to List of LBI
Related FW 3.0.0 Related applications All
Comm object 16
Description
Active input blocks protections that are configured as “Force Block 1” Prot. block type. Corresponding
setpoint is ForceBlockDel1.
Force Block 1
6 back to List of LBI
Related FW 3.0.0 Related applications All
Comm object 17
Description
Active input blocks protections that are configured as “Force Block 2” Prot. block type. Corresponding
setpoint is ForceBlockDel2.
Force Block 2
6 back to List of LBI
Related FW 3.0.0 Related applications All
Comm object 18
Description
Active input blocks protections that are configured as “Force Block 3” Prot. block type. Corresponding
setpoint is ForceBlockDel3.
Force Block 3
6 back to List of LBI
