InteliDrive DCU Marine - 3.0.0 Global Guide
13
CAN control + Engine
stop
Stop from ID-DCU-MARINE
RS232 control +
Engine stop
Stop from InteliMonitor
Stop button ID-DCU MARINE panel button
Other Events
Fault reset ID-DCU MARINE panel button
LOC mode ON ID-DCU MARINE panel button
LOC mode OFF ID-DCU MARINE panel button
HRB mode ON ID-DCU MARINE panel button
HRB mode OFF ID-DCU MARINE panel button
RS232 control
Start, Stop, Fault reset, I/0 button from InteliMonitor or
ID-DCU-MARINE
RS485 control
Start, Stop, Fault reset, I/0 button from InteliMonitor or
ID-DCU-MARINE
Modem control Start, Stop, Fault reset, On/Off from Modem
SMS control Received command from GSM modem
CAN control Received command via CAN bus e.g. from ID-DCU-MARINE or IG-IB/IB-NT
ActCallCH1-OK Successful active call on channel 1
ActCallCH2-OK Successful active call on channel 2
ActCallCH3-OK Successful active call on channel 3
ActCallCH1Fail Failure of active call on channel 1
ActCallCH2Fail Failure of active call on channel 2
ActCallCH3Fail Failure of active call on channel 3
Extern start Manual engine starter handling.
Engine stop Engine changed state from
Emerg.man ON Emergency manual mode ON
Emerg.man OFF Emergency manual mode OFF
Clutch ON Binary output clutch was closed
Clutch OFF Binary output clutch was opened
Switched on Controller was switched on
Cfg loaded Configuration archive was changed
FwLoaded Firmware upgrade
Time stamp Depends on setpoint setting period
Password set Any level from any terminal
Password changed Any level from any terminal
Access set Access code was set
Access changed Access code was changed
Watchdog Controller internal watchdog protection
