© 06/2006 8163-001
5/6
TCD 2015
Drive system
W 02-01-04
6
z Tighten screws (arrows).
Attention!
Screws can be reused a maximum 3 times
with written documentation.
© 40597-0
z Lightly oil screws (1).
z Tighten screws (1).
Attention!
Screws can be reused a maximum 3 times
with written documentation.
1
© 40599-0
z Tighten screws (arrow) with the socket wrench
insert size 24 and rotation angle disc.
A02 010
© 40491-0
