TCD 2015
Other components
W 12-06-01
© 06/2006 8241-001
2/2
6
z Visually inspect the components.
© 40903-0
Install flywheel
z Position friction disc.
z Mount flywheel.
Make sure the clamping bushing (1) is in
place.
Make sure the clamping bushing and loca-
ting hole are in line.
1
© 40966-0
z Insert thrust washer (2).
z Lightly oil screws (1).
z Fasten all screws (1).
z Remove self-made mandrin guide.
z Tighten all screws (1) with the socket wrench insert.
A12 001
Attention!
Renew screws every time they are loo-
sened.
Block flywheel with suitable tool.
2
1
© 40658_1
