TCD 2015
Crankcase
I 03-10-05
© 06/2006 8182-001
2/8
6
Grinding for cleaning the collar rest
z Apply post-grinding paste (1) to the collar rest (2).
z Add a little clean water.
1 2
© 39908-0
z Mount the bracket and handles on the grinding/sur-
face plate.
z Place grinding side “A“ on collar rest.
Note the different processing sides of the
grinding/surface plate:
A - grinding side
B - surface side
Grinding side “A“ faces down.
A
© 39904-0
z Turn the grinding/surface plate (1) forwards and
backwards evenly (approx. 180°).
z Grind the collar rest lightly.
z Clean the collar rest.
z Remove grind paste and grinding particles.
Note soft grinding noise.
Use cleaning agent.
1
© 39906-0
