Deutz TCD 2015 - Checking the Crankshaft

© 06/2006 8164-001
1/6
TCD 2015
Drive system
W 02-01-07
6
Checking the crankshaft
Commercial available tools:
– Magnetic measuring stand
– Micrometer gauge
– Internal measuring device
– Prisms
– Hardness tester
Special tools:
– Dial gauge. . . . . . . . . . . . . . . . . . 100400
– W 02-04-01
z Remove crankshaft.
 W 02-04-01
z Place crankshaft on prism.
© 40485-0
z Pull off gear wheel (1).
z Remove friction disc.
1
© 40585-0
