TCD 2015
Engine control
W 04-06-03
6
Installing and removing turning gear
Commercial available tools
Special tools:
– Turn-over gear . . . . . . . . . . . . . . 100300
– Locking agent
DEUTZ DW 59
The turning gear 100350 can be used at
the front end of the crankshaft depending
on the installation relations.
Attaching turning gear
z Unscrew screws (1).
z Remove cover (2).
z Remove gasket.
1
2
© 40461-0
z Insert turn-over gear (1).
z Insert centering pin (2) in threaded bore (3).
1
3
2
© 40462-0
