Deutz TCD 2015 - Lube Oil Pressure Data; Cooling System Data; Other Components Data

4
© 06/2006 8145-001
12/28
TCD 2015
Technical data
Testing and setting data
P07 91 Installation dimensions of the fuel shut-off valve dimension X TCD 2015 approx. 25 mm
P07 92 Installation angle of the fuel pipe dimension X TCD 2015 approx. 30 °
Lubricating oil system Lube oil pressure P08 63
Basic setting of the pressurestat when using new parts
for 3.00 bar
TCD 2015
35
mmfor 3.50 bar 32
for 4.00 bar 29.1
Cooling system P09 11 Thermostat, start opening (A-bank)
Coloured marking black venting notch top
TCD 2015 79 °C
P09 12 Thermostat, start opening (B-bank) Venting notch top TCD 2015 87 °C
P09 13 Thermostat, stroke distance TCD 2015 at least 8 mm
Other components P12 11
Tension of the single V-belt (first assembly, gene- rator, 120 Ampere)
with V-belt tension measuring device 8115
TCD 2015
500 N
Tension of the single V-belt (first assembly, gene- rator, 55 Ampere)
with V-belt tension measuring device 8115
550 N
P12 21
Tension of the single V-belt (generator, 120 Am- pere)
Check after 15 minutes running under load
TCD 2015
350 N
Tension of the single V-belt (generator, 55 Ampe- re)
Check after 15 minutes running under load
300 N
P13 66
Screw-in height of the flame glow plug in connec- ting line
dimension X TCD 2015 60 mm
ID no. Name Information Series Value Unit
+5
-5
0
+5
-5
0
+5
-5
0
0
-
3
