© 06/2006 8235-001
1/6
TCD 2015
Cooling system
W 09-07-08
6
Removing and installing the coolant pump
Commercial available tools
Special tools:
– Disassembly tool. . . . . . . . . . . . . 110901
– Fitting compound
DEUTZ AP1908
Collect leaking operating substances in
suitable vessels and dispose of according
to regulations.
Removing coolant pump
z Unscrew screws (1).
z Removing screw-in nipple (2).
z Remove gasket.
1
2
© 40870_1
z Visually inspect the components.
© 45393-0
