TCD 2015
Fuel system
W 07-04-01
© 06/2006 8216-001
6/10
6
z Lightly oil screws (1).
z Tighten screws (1).
A07 009
1
© 45388-0
z Install fuel pipes.
W 07-10-06
z Install fuel pipes (Railway).
W 07-10-06
Do not install fuel pipe (1).
Do not install charge air pipe (A-bank).
1
© 45391-0
Installing the fuel injector pump
Note the assignment of the injection pump/
roller tappet when replacing the injection
pump and/or roller tappet.
© 40807-0
