Deutz TCD 2015 - Remove and Install the Charge Air Line

© 06/2006 8200-001
1/4
TCD 2015
Exhaust system/Charging
W 06-02-03
6
Remove and install the charge air line
Commercial available tools
– Fitting compound
DEUTZ AP1908
Remove charge air line
z Unscrew screws (1).
z Remove charge air pipe (2) with plug.
1
1
2
© 40764-0
z Pull out plug element (1).
1
© 40765-1
