© 06/2006 8180-001
1/4
TCD 2015
Crankcase
W 03-09-01
6
Removing and installing rear cover
Commercial available tools
– Locking agent
DEUTZ DW 59
– W 02-02-02
– W 03-09-04
– W 08-04-07
Removing rear cover
z Remove connection housing.
W 03-09-04
z Remove lubricating oil pan.
W 08-04-07
z Unscrew all screws (1).
z Remove rear cover 2.
z Remove gasket.
1
2
© 40684-0
z Knock out crankshaft sealing ring (1).
Attention!
Do not damage the sealing surfaces.
1
© 37207-1
