Deutz TCD 2015 - Valve Spring Data; Valve Clearance Data; Rocker Arm;Bracket Data

4
© 06/2006 8145-001
6/28
TCD 2015
Technical data
Testing and setting data
P01 46 Valve stand back dimension (outlet)
Standard (from the center of the valve head to the cylinder head sealing surface)
TCD 2015 2.4 mm
Wear limit (from the center of the valve head to the cylinder head sealing surface)
TCD 2015 1.25 - 1.65 mm
Valve spring P01 51
Valve spring length untensioned, normal
TCD 2015
58.7
mm
Valve spring wire diameter 4.25
Valve clearance P01 61 Valve clearance (inlet)
with rotation angle disc
TCD 2015
90 °
with cold engine with feeler gauge
0.25 mm
P01 62 Valve clearance (outlet)
with rotation angle disc
TCD 2015
108 °
with cold engine with feeler gauge
0.30 mm
P01 63 Valve clearance setting
Valve overlap according to adjustment schematic
TCD 2015 T01 63 -
Rocker arm/bracket P01 72 Rocker arm, bore, diameter (outlet) TCD 2015 28 mm P01 73 Rocker arm, bore, diameter (inlet) TCD 2015 28 mm
P01 74 Rocker arm shaft (diameter) TCD 2015 28 mm
P01 75 Axial clearance of the toggle levers Axial bearing clearance with cold engine TCD 2015 0.2 - 0.4 mm
ID no. Name Information Series Value Unit
+1
+0.
0
+1
+0.
0
+0
.
02
0
+0
.
02
0 -
0
.
04
-0.0
6
