© 06/2006 8244-001
1/20
TCD 2015
Electrical system
W 13-01-02
6
Removing and installing the cable harness
Commercial available tools – W 06-02-03
Attention!
Note assignment and polarity of the electri-
cal connections!
Removing the cable harness
z Remove the charge air pipe.
W 06-02-03
© 40916-0
z Disconnect the battery's negative terminal.
z Disconnect cables.
© 40917-0
