© 06/2006 8232-001
1/8
TCD 2015
Lube oil system
W 08-08-02
6
Removing and installing the oil cooler
Commercial available tools – W 06-07-03 . . . . . . . . . . . . (A-bank)
– W 09-08-04
Collect leaking operating substances in
suitable vessels and dispose of according
to regulations.
Removing the oil cooler
z Remove charge air pipe (A-bank).
W 06-07-03
z Remove thermostat housing.
W 09-08-04
© 40849-0
z Unscrew screws (1).
z Remove the holder (2).
1
2
© 40519-0
