Deutz TCD 2015 - Installing the Rocker Arm and Rocker Arm Bracket

TCD 2015
Cylinder head
W 01-02-02
© 06/2006 8151-001
2/6
6
z Remove push rods (1).
Lay out components in the order in which
they should be installed.
1
© 42219-1
z Visually inspect the components.
© 34824-2
Installing the rocker arm and rocker arm
bracket
z Insert stop rods (1).
Note assignment!
1
© 42219-1
