Deutz TCD 2015 - Camshaft Data; Speed Governing System Data; Fuel System Data; Injection Valve Data

4
© 06/2006 8145-001
11/28
TCD 2015
Technical data
Testing and setting data
P03 36 Collar height of cylinder liner TCD 2015 9.02 mm
P03 37 Thickness of shim Standard TCD 2015 1.0 mm P03 39 Overhang of cylinder liner TCD 2015 0.09 mm
Control system Camshaft P04 31 Camshaft bearing pin diameter Standard TCD 2015 70 mm P04 35 Axial clearance of the camshaft TCD 2015 0.25 - 0.75 mm
P04 37
Thickness of the gasket for axial clearance set- ting
TCD 2015 0.3 mm
P04 39
Overhang of the parallel pin on the camshaft gear wheel
TCD 2015 5.000 mm
P04 43
Axial clearance of the camshaft for injection pumps
TCD 2015 0.2 - 0.45 mm
P04 44
Tooth edge clearance of the idler gear - idler gear to camshaft gear wheel
TCD 2015 0.04 - 0.3 mm
Speed governing system P05 91
Clearance between speed governor (crankshaft) and flywheel
TCD 2015 1.0 mm
P05 92
Clearance between speed governor (camshaft) and camshaft gear wheel
TCD 2015 0.3 - 0.9 mm
Fuel system P07 19 Plunger lift of the camshaft for injection pumps see name plate TCD 2015 4.00 mm
P07 20
Tooth edge clearance between gear wheel of the camshaft for injection pumps and camshaft gear wheel
TCD 2015 0.04 - 0.3 mm
Injection valve P07 52 Nozzle opening pressure of the fuel injector TCD 2015 280 - 288 bar ID no. Name Information Series Value Unit
0
-0.0
+0
.
0
-0.0
-
0
.
06
-0.0
7
+0.
