© 06/2006 8242-001
1/4
TCD 2015
Other components
W 12-06-03
6
Renewing toothed starter ring on the flywheel
Commercial available tools – W 12-06-01
Danger!
Danger of injury, do not touch hot parts!
Removing toothed starter ring
z Remove flywheel.
W 12-06-01
z Check marking.
The marking (arrow) is on the flywheel and
exactly in the middle of the tooth notch of
the toothed starter ring.
© 40904-0
z Remove toothed starter ring with suitable tool.
© 34764-2
