TCD 2015
Technical data
Testing and setting data
Piston pin P02 61 Piston pin, diameter TCD 2015 51.992 - 52.000 mm P02 62 Piston pin clearance Wear limit TCD 2015 0.09 mm Piston P02 71 Piston, diameter
Measuring point 1 at height 22.5 mm (Identification of the installation position on the piston head)
TCD 2015 132 mm
P02 72 Piston, diameter
Measuring point 2 at height 87.5 mm (Identification of the installation position on the piston head)
TCD 2015 132 mm
P02 73 Piston, diameter
Measuring point 3 at height 122.7 mm (Identification of the installation position on the piston head)
TCD 2015 132 mm
P02 75 Piston projection 1.4 = 1 hole (cylinder head gasket) TCD 2015 -0.05 to 0.10 mm P02 76 Piston projection 1.6 = 2 holes (cylinder head gasket) TCD 2015 0.10 to 0.30 mm
P02 77 Piston projection 1.8 = 3 holes (cylinder head gasket) TCD 2015 0.30 to 0.51 mm
P02 78 Piston pin, bore TCD 2015 52 mm
Piston rings P02 84 Closed gap, piston ring 1
Standard
TCD 2015
0.35 - 0.45 mm
Wear limit (identification TOP in direction of piston head)
0.9 mm
P02 85 Closed gap, piston ring 2
Standard
TCD 2015
1.1 - 1.3 mm
Wear limit (identification TOP in direction of piston head)
1.4 mm
