TCD 2015
Drive system
W 02-09-03
6
z Visually inspect the components.
© 40592-0
z Remove locking ring with locking ring pliers.
z Press out piston pin.
z Remove locking ring with locking ring pliers.
z Visually inspect the components.
Attention!
Make sure the surface of the piston is flaw-
less.
© 42377-1
Installing the piston and con rod
z Insert new locking ring.
Ensure that the installation location is free
from faults.
© 42378-1
